Muffler Oval In-76 Out-63 140/220mm L=500mm
160,00 €
Oval stainless steel muffler 140x220mm body, 500mm length, 76mm inlet to dual 63.5mm outlets, center/dual configuration.
Oval Muffler In-76 Out-2×63.5 140/220mm L-500mm Stainless Steel
The Oval Muffler 140/220mm L-500mm 76–2×63.5 SS is a long-body stainless steel exhaust muffler designed for performance systems requiring a single inlet and dual outlet configuration.
This model features an oval body size of 140mm x 220mm and an extended 500mm body length, providing enhanced sound reduction and a deeper exhaust tone while maintaining smooth exhaust flow.
It is built with a 76mm (3″) single inlet and dual 63.5mm (2.5″) outlets, using a center/dual pipe configuration, making it ideal for single-to-dual exhaust conversions and custom performance builds.
Constructed from high-quality stainless steel, this muffler ensures excellent resistance to corrosion, vibration, and extreme exhaust temperatures. The straight-through internal core minimizes backpressure while delivering balanced sound performance.
This solution is ideal for performance vehicles, turbocharged engines, and stainless steel exhaust upgrades requiring improved noise control.
Key Features
-
Oval body 140mm x 220mm
-
Extended 500mm length for improved sound reduction
-
76mm (3″) single inlet
-
Dual 63.5mm (2.5″) outlets
-
Center/dual configuration
-
Straight-through performance core
-
Stainless steel construction
-
High heat and corrosion resistance
Technical Specifications
-
Body shape: Oval
-
Body size: 140mm x 220mm
-
Body length: 500mm
-
Inlet position: Center
-
Outlet configuration: Dual
-
Inlet inner diameter: 76mm
-
Outlet inner diameter: 2 x 63.5mm
-
Each side pipe length: 70mm
-
Material: Stainless Steel
Applications
The Oval Muffler 140/220mm L-500mm 76–2×63.5 SS is suitable for:
-
Single-to-dual exhaust conversions
-
Performance exhaust systems
-
Custom dual exhaust fabrication
-
3-inch inlet exhaust builds
-
Turbocharged vehicles
-
Stainless steel exhaust upgrades
-
Professional workshop installation
Professional installation is recommended.
| Weight | 5 kg |
|---|
